OCTAGON SF8008 4K UHD DVB-S2X

Octagon SF8008 Twin V2	VS Support	uClan Ustym 4K PRO
YES	Fotelka 51.5°E	NO
YES	Stremlink	NO

Denis OS Ustym

Wifi - rtl8192eu
Tuner A Si2166D (DVB-S2X)

Tuner B ATBM7821 DVB-T2/C (DVB-T2)

Chipset - 3798mv200

SF8008 + LCD Display

Fotelka 51.5E SF8008 Twin V2 Work - 11230 H 45000 8/9 * 11290 H 45000 8/9

Recovery Menu

V1.0-06/01/2020

V1.0-06/24/2020

Dreambox Edit

Data - 0

Radio - 2

SD - 1

HD - 25

UHD / h.265 - 31

Kodi 4:2:2

StreamLink

Info install ok

Info

Hex Decoder

Youtube , FilmOn , canlitvlive , MediaKlikk ...

http://127.0.0.1:8088/http://

1. #SERVICE 4097:0:1:1:0:0:0:0:0:0:http%3a//127.0.0.1%3a8088

1 #DESCRIPTION TGRT EU

2. #SERVICE 5002:0:1:1:0:0:0:0:0:0:http%3a//127.0.0.1%3a8088

2. #DESCRIPTION TGRT EU

3 .#SERVICE 4097:0:1:1:0:0:0:0:0:0:http%3a//127.0.0.1%3a8088https%3a//www.

Amsterdam

http://127.0.0.1:8088/https://www.youtube.com/watch?v=jBmWECpF_HQ

De 4k live webcams werken goed als ik een resolutie aan de link toevoeg (vb. met 720p en 1080p)

http://127.0.0.1:8088/q=1080p/https://www.youtube.com/watch?v=jBmWECpF_HQ

#SERVICE 4097:0:1:1:0:0:0:0:0:0:http%3a//127.0.0.1%3a8088/q=720p/https%3a//www.youtube.com/watch?v=jBmWECpF_HQ
#DESCRIPTION Amsterdam - Dam
#SERVICE 4097:0:1:1:0:0:0:0:0:0:http%3a//127.0.0.1%3a8088/q=1080p/https%3a//www.youtube.com/watch?v=jBmWECpF_HQ
#DESCRIPTION Amsterdam - Dam

(YT streams werken bij mij met zowel #SERVICE 4097 als met #SERVICE 5002)

Bűvítmények - Plugins

var/lib/opkg/lists/

etc/opkg/

E2iPlayer Install

http://www.e2iplayer.gitlab.io

opkg install http://www.blindspot.nhely.hu/e2iplayer_Hungarian_all.ipk

reboot

opkg update

opkg install ffmpeg

opkg install exteplayer3

opkg install enigma2-plugin-systemplugins-serviceapp

https://cesbo.com/en

dvbsnoop is a DVB / MPEG stream analyzer program

opkg install dvbsnoop

dvbsnoop -s pidscan

dvbsnoop -n 1 -nph 0x0203

0x0203 channel video pid

http://dvbsnoop.sourceforge.net/dvbsnoop.html

dvbsnoop -s pidscan | grep datagram

astra --analyze pipe://"dvbsnoop 515 -b"

515 pid

astra --analyze http://127.0.0.1:8001/1:0:1:2CA:1B58:13E:820000:0

https://www.sat-universe.com/showthread.php?t=315709&page=7

https://www.satdreamgr.com/forum/showthread.php?14415-How-to-use-DVB-Multiprotocol-Encapsulation

http://enosat.euweb.cz/dvbip.htm

https://en.wikipedia.org/wiki/Multiprotocol_Encapsulation

https://linuxtv.org/downloads/v4l-dvb-apis/net.html
https://linuxtv.org/wiki/index.php/InternetDVB

http://old.slax.org/forum.php?action=view&parentID=12189
https://ubuntuforums.org/showthread.php?t=1413438

cd /tmp && rm -f ffinstall.py && wget http://e2iplayer.pkteam.pl/ffinstall.py && python ffinstall.py

cd /tmp && rm -f ffinstall && wget http://softrix.co.uk/istream/precompiled/ffinstall && python ffinstall

Plugins Feeds

Ustym 4K Feeds

mulholland2 - Vodafone / UPC kábel TV piconok:
https://drive.google.com/file/d/1Z1QPgUy-zLkUybWXCBhzW2XWXHr3yzJm/view?usp=sharing

Webtv_usr.xml szerkesztő - Gilszkilabor

Andoid Apps

Signal Meter E2 - Szignálra

Dream Player - TV-t Nézni

aplikácia E2TV Streamelni más készülékről

Define OS - Denys

Információk:

Gyári PIN: 0000
Fő PIN: 8899
CA, PIN aktiválása kód: 6836 (írja be a beállítások menübe)
Gyors hozzáférés a kulcsszerkesztőhöz, PIN kód: 6969 (írja be a csatorna nézése közben)
Írja be a BISS kulcs gyors szerkesztését, PIN kód: 0000 (adja meg a csatorna nézése közben)

Támogatott USB-WiFi adapterek:

RT5370 (B / G / N-sávok 150Mbit / s 2.4Ghz Mediatek)
MT7601 (B / G / N-sávok 150Mbit / s 2.4Ghz Mediatek)
RTL8188 (B / G / N-sávok 150Mbit / s 2.4Ghz Realtek)
RTL8188EU (B / G / N-sávok 150Mbit / s 2.4Ghz Realtek)
RTL8188FU ( B / G / N-sávok 150Mbit / s 2.4Ghz Realtek, SW 1.05.00 és újabb)
RTL8192CU (B / G / N-300Mbit / s sávok 2.4Ghz Realtek, SW 1.04.64 és újabb)
RTL8192EU (B / G / N-sávok 300Mbit / s 2.4Ghz Realtek, szoftver 1.06.04 és újabb)
RTL8192DU (A / B / G / N-300Mbit / s sávok 2.4Ghz / 5.8Ghz Realtek, szoftverek 1.07.00 és újabb)
RTL8811СU (A / B / G / N / AC-sávok 600Mbit / s 2.4 / 5.8Ghz Realtek, szoftver 1.07.00 és újabb)
RTL8812BU (A / B / G / N / AC-sávok 1200Mbit / s 2.4 / 5.8Ghz Realtek, szoftver 1.06.05 és újabb)

Link

KODI

https://kodi-addons.club/addon/script.video.RobinHoodTv/

https://tvboxbee.com/how-to-install-robin-hood-tv-addon-on-kodi/

https://www.youtube.com/watch?v=sYSq-yGbh4w

XML Tester Online / 2

http://www.blindspot.nhely.hu/e2iplayer_Hungarian_all.ipk

Oscam Info

Changeset

Timeline

CAID / 0 / 1 / 2

PES PAT PMT CAT NIT TID SDT TID BAT EIT TDT infó

Régi : 1_0_1_A8C_2_5E_E08B00F_0_0_0
Új : 1_0_1_A8C_2_5E_E080000_0_0_0

30W Abertis DTT

lamedb

userbouquet.erik1dj_30w_abertis.tv

bouquets.tv

#NAME User - bouquets (TV)

#SERVICE 1:7:1:0:0:0:0:0:0:0:FROM BOUQUET "userbouquet.erik1dj_30w_abertis.tv" ORDER BY bouquet

lamedb

Discovery Hungary HD p:,c:000384,c:010386,c:030384,c:050001,C:0e00,f:1004

DTX p:,c:000bb8,c:030bb8,c:040bbc,c:050001,C:0e00,f:1004

{
*video_pid = 0x384;
demux[demux_id].STREAMpidsType[demux[demux_id].STREAMpidcount] = STREAM_VIDEO;
demux[demux_id].STREAMpids[demux[demux_id].STREAMpidcount] = *video_pid;
demux[demux_id].STREAMpidcount++;
}

{
*video_pid = 0xbb8;
demux[demux_id].STREAMpidsType[demux[demux_id].STREAMpidcount] = STREAM_VIDEO;
demux[demux_id].STREAMpids[demux[demux_id].STREAMpidcount] = *video_pid;
demux[demux_id].STREAMpidcount++;
}

4.8E Zeonbud T2-MI StreamRelay

astra.conf

-- Astra Slonik Mod

log.set({ stdout = false, debug = false, syslog = "astra", })

-- ZeonBUD 4,8E

ze48mis10 = make_t2mi_decap({
name = "12188 MIS 10", -- required
input = "http://127.0.0.1:8001/1:0:1:1:48:10:30B022:0:0:0:", -- required
plp = 0, -- optional, defaults to first PLP listed in L1
pnr = 0, -- optional, PNR containing T2-MI payload
pid = 4096, -- optional, force payload pid
})

ze48mis20 = make_t2mi_decap({
name = "12188 MIS 20",
input = "http://127.0.0.1:8001/1:0:1:1:48:20:30B022:0:0:0:",
plp = 0,
pnr = 0,
pid = 4096,
})

ze48mis30 = make_t2mi_decap({
name = "12341 MIS 30",
input = "http://127.0.0.1:8001/1:0:1:1:48:30:30B022:0:0:0:",
plp = 0,
pnr = 0,
pid = 4096,
})

make_channel({
name = "mis 10", input = { "t2mi://ze48mis10", },
output = { "http://0.0.0.0:9999/zeonbud/mis10", },
})

make_channel({
name = "mis 20", input = { "t2mi://ze48mis20", },
output = { "http://0.0.0.0:9999/zeonbud/mis20", },
})

make_channel({
name = "mis 30", input = { "t2mi://ze48mis30", },
output = { "http://0.0.0.0:9999/zeonbud/mis30", },
})

lamedb

eDVB services /4/
transponders
0030b022:0048:0010
   s 12188000:30000000:0:3:48:2:0:1:2:0:2:10:0:1
/
0030b022:0048:0020
   s 12188000:30000000:0:3:48:2:0:1:2:0:2:20:0:1
/
0030b022:0048:0030
   s 12341000:30000000:0:3:48:2:0:1:2:0:2:30:0:1
/
end
services
0001:0030b022:0048:0010:1:0
12188H MIS 10
p:ZEONBUD,c:151000,f:4
0001:0030b022:0048:0020:1:0
12188H MIS 20
p:ZEONBUD,c:151000,f:4
0001:0030b022:0048:0030:1:0
12341H MIS 30
p:ZEONBUD,c:151000,f:4
end
Have a lot of bugs!

Bouquets

#NAME T2-MI Zeonbud 4.8E
#SERVICE 1:64:2E:0:0:0:0:0:0:0::MultiStream 10 T2-MI
#DESCRIPTION MultiStream 10 T2-MI
#SERVICE 1:0:1:1:48:10:30B022:0:0:0::12188H MIS 10 T2-MI
#DESCRIPTION 12188H MIS 10 T2-MI
#SERVICE 1:0:1:B:48:10:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis10:Інтер
#DESCRIPTION Інтер
#SERVICE 1:0:1:C:48:10:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis10:Україна
#DESCRIPTION Україна
#SERVICE 1:0:1:D:48:10:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis10:1+1
#DESCRIPTION 1+1
#SERVICE 1:0:1:E:48:10:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis10:НТН
#DESCRIPTION НТН
#SERVICE 1:0:1:F:48:10:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis10:К-1
#DESCRIPTION К-1
#SERVICE 1:0:1:10:48:10:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis10:ПЕРШИЙ Т2
#DESCRIPTION ПЕРШИЙ Т2
#SERVICE 1:0:1:11:48:10:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis10:ICTV
#DESCRIPTION ICTV
#SERVICE 1:0:1:12:48:10:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis10:Enter-фільм
#DESCRIPTION Enter-фільм
#SERVICE 1:64:2F:0:0:0:0:0:0:0::MultiStream 20 T2-MI
#DESCRIPTION MultiStream 20 T2-MI
#SERVICE 1:0:1:1:48:20:30B022:0:0:0::12188H MIS 20 T2-MI
#DESCRIPTION 12188H MIS 20 T2-MI
#SERVICE 1:0:1:15:48:20:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis20:ZOOM
#DESCRIPTION ZOOM
#SERVICE 1:0:1:16:48:20:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis20:Кіноточка
#DESCRIPTION Кіноточка
#SERVICE 1:0:1:17:48:20:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis20:СТБ
#DESCRIPTION СТБ
#SERVICE 1:0:1:18:48:20:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis20:ТЕТ
#DESCRIPTION ТЕТ
#SERVICE 1:0:1:19:48:20:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis20:К-2
#DESCRIPTION К-2
#SERVICE 1:0:1:1A:48:20:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis20:Новий канал
#DESCRIPTION Новий канал
#SERVICE 1:0:1:1B:48:20:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis20:М-1
#DESCRIPTION М-1
#SERVICE 1:0:1:1C:48:20:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis20:5 канал
#DESCRIPTION 5 канал
#SERVICE 1:64:30:0:0:0:0:0:0:0::MultiStream 30 T2-MI
#DESCRIPTION MultiStream 30 T2-MI
#SERVICE 1:0:1:1:48:30:30B022:0:0:0::12341H MIS 30 T2-MI
#DESCRIPTION 12341H MIS 30 T2-MI
#SERVICE 1:0:1:1F:48:30:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis30:Мега
#DESCRIPTION Мега
#SERVICE 1:0:1:20:48:30:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis30:Pixel
#DESCRIPTION Pixel
#SERVICE 1:0:1:21:48:30:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis30:XSPORT
#DESCRIPTION XSPORT
#SERVICE 1:0:1:22:48:30:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis30:НЛО ТБ
#DESCRIPTION НЛО ТБ
#SERVICE 1:0:1:23:48:30:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis30:2+2
#DESCRIPTION 2+2
#SERVICE 1:0:1:24:48:30:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis30:DOBRO
#DESCRIPTION DOBRO
#SERVICE 1:0:1:25:48:30:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis30:ЕСПРЕСО TV
#DESCRIPTION ЕСПРЕСО TV
#SERVICE 1:0:1:26:48:30:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis30:BUSINESS
#DESCRIPTION BUSINESS
#SERVICE 1:0:1:65:48:30:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis30:Газета по-русски
#DESCRIPTION Газета по-русски
#SERVICE 1:0:1:66:48:30:0:0:0:0:http%3a//localhost%3a9999/zeonbud/mis30:Газета українскою
#DESCRIPTION Газета українскою
#SERVICE 1:64:31:0:0:0:0:0:0:0::MultiStream 40 12341H
#DESCRIPTION MultiStream 40 12341H
#SERVICE 1:0:1:2:190:2324:300000:0:0:0:
#SERVICE 1:0:1:5:190:2324:300000:0:0:0:
#SERVICE 1:0:16:2B:190:2324:300000:0:0:0:
#SERVICE 1:0:16:320:190:2324:300000:0:0:0:
#SERVICE 1:0:16:2C:190:2324:300000:0:0:0:
#SERVICE 1:0:19:29:190:2324:300000:0:0:0:
#SERVICE 1:0:16:2A:190:2324:300000:0:0:0:
